Fetal Pig Dissection and Lab Guide External Anatomy of the Fetal Pig. Determine the sex of your pig by looking for the urogenital opening. On females, this opening is located near the anus. On males, the opening is located near the umbilical cord. If your pig is female, you should also note that urogenital papilla is present near the genital.
External Anatomy of the Fetal Pig
1. Determine the sex of your pigby looking for the urogenital opening. On females, this opening is located nearthe anus. On males, the opening is located near the umbilical cord.
If your pig is female, you shouldalso note that urogenital papilla is present near the genital opening. Malesdo not have urogenital papilla.
Both males and females have rowsof nipples, and the umbilical cord will be present in both. What sex is your pig? _________
2. Make sure you are familiar withterms of reference: anterior, posterior, dorsal, ventral. In addition, you'llneed to know the following terms
Medial: toward the midline or middleof the body | Lateral: toward the outside of the body
Proximal: close to a point of reference | Distal: farther from a point of reference
3. Open the pig's mouth and locatethe hard and soft palate on the roof of the mouth. Can you feel your own hardand soft palates with your tongue?
Note the taste buds (also known assensory papillae) on the side of the tongue. Locate the esophagus at the backof the mouth. Feel the edge of the mouth for teeth.
Does the fetal pig haveteeth? ________ How many? ______
Are humans born with teeth? ________
4. Use a scalpel to cut the angles of the jaw so that you can open the mouth up far enough to view the back of the throat. Locate the epiglottis, a cone-shaped structure which closes when a pig swallows. The small opening in the center of the epiglottis is the glottis and it leads to the trachea and then to the lungs. Make sure that you can distinguish the glottis from the esophagus.
5. Gestation for the fetal pig is112-115 days. The length of the fetal pig can give you a rough estimate of itsage.
11mm - 21 days | 17 mm - 35 days | 2.8 cm - 49 days
4 cm - 56 days | 22 cm - 100 days | 30 cm -- birth
How old is your fetal pig? ______
6. Observe the toes of the pig. Howmany toes are on the feet? _________________
7. Observe the eyes of the pig, carefullyremove the eyelid so that you can view the eye underneath.
Does it seem welldeveloped? Do you think pigs are born with their eyes open or shut? _________________________________
8. Carefully lay the pig on one sidein your dissecting pan and cut away the skin from the side of the face and upperneck to expose the masseter muscle that works the jaw, lymph nodes, and salivaryglands. The salivary glands kind of look like chewing gum, and are often lostif you cut too deeply.
Image Credit: Fetal Pig Dissection Manual, Alexandra Altamura
The Anatomy of the Fetal Pig (internal)
In this activity, you willopen the abdominal and thoracic cavity of the fetal pig and identify structures.Remember, that to dissect means to 'expose to view' - a careful dissectionwill make it easier for you to find the organs and structures. Be sure to followall directions.
The Incision
Place your fetal pigin the dissecting pan ventral side up. Use string to 'hog-tie'your pig so that the legs are spread eagle and not in your way. Use scissorsto cut through the skin and muscles according to the diagram. Do not removethe umbilical cord. In the first section, you will only examine the abdominalcavity (the area below the ribcage).
After completing thecuts, locate the umbilical vein that leads from the umbilical cord tothe liver. You will need to cut this vein in order to open up the abdominalcavity.
Your pig may be filledwith water and preservative, drain over the sink if necessary and rinseorgans. Locate each of the organs below, check the box. ✔
1. Diaphragm. Thismuscle divides the thoracic and abdominal cavity and is located near the ribcage.
The diaphragm aids in breathing.
2. Liver. This structure is lobed and is the largest organ in the body.The liver is responsible for making bile for digestion.
3. Gall bladder. This greenish organ is located underneath the liver;the bile duct attaches the gall bladder to the duodenum. The gall bladder storesbile and sends it to the duodenum, via the bile duct.
4. Stomach. A pouch shaped organ that rests just underneath and to thepig's left. At the top of the stomach, you'll find the esophagus. The stomachis responsible for churching and breaking down food.
5. At each end of the stomach are valves that regulate food entering and leavingthe stomach. At the esophagus is the cardiac sphincter valve, and atthe duodenum is the pyloric sphincter valve. View the inside of the stomachby slicing it open lengthwise.
6. The stomach leads to the small intestine, which is composed of theduodenum (straight portion just after the stomach) and the ileum (curlypart).
7. The ileum is held together by mesentery. In the small intestine, furtherdigestion occurs and nutrients are absorbed through the arteries in the mesentery.These arteries are called mesenteric arteries.
8. Pancreas: a bumpy organ located along the underside of the stomach,a pancreatic duct leads to the duodenum. The pancreas makes insulin, which isnecessary for the proper uptake of sugars from the blood.
9. Spleen: a flattened organ that lies across the stomach and towardthe extreme left side of the pig. The spleen stores blood and is not part ofthe digestive system. On the underside of the spleen, locate the splenic artery.
10. At the end of the ileum, where it widens to become the large intestine,a 'dead-end' branch is visible. This is the cecum. The cecumhelps the pig digest plant material.
11. The large intestine can be traced to the rectum. The rectum liestoward the back of the pig and will not be moveable. The rectum opens to theoutside of the pig, or the anus. The large intestine reabsorbs water from thedigested food, any undigested food is stored in the rectum as feces.
12. Lying on either side of the spine are two bean shaped organs: the kidneys.The kidneys are responsible for removing harmful substances from the blood,these substances are excreted as urine. (more on this later)
13. Two umbilical vessels can be seen in the umbilical cord, and theflattened urinary bladder lies between them.
1. __________________________________
2. __________________________________
3. __________________________________
4. __________________________________
5. __________________________________
6. __________________________________
7. __________________________________
8. __________________________________
9. __________________________________
10. _________________________________
11. _________________________________
12. _________________________________
13. _________________________________
Identify the organ (or structure)
14. _____________________________A branch of the large intestine, a dead end.
15. _____________________________ Stores bile, lies underneath the liver.
16. _____________________________ Opening (valve) between the stomach and small intestine.
17. _____________________________ Empties bile into the duodenum from the gallbladder.
18. _____________________________ The last stretch of the large intestine before it exits at the anus.
19. _____________________________ Bumpy structure under the stomach; makes insulin
20. _____________________________ Separates the thoracic and abdominal cavity; aids breathing.
21. _____________________________ Membrane that holds the coils of the small intestine.
22. _____________________________ The straight part of the small intestine, just after the stomach.
23. _____________________________ Lies between the two umbilical vessels.
Urinary and Reproductive Systems (Urogenital)
1. Locate the kidneys; which are bean shaped structures lying toward the back of the abdomen.
2. The ureters are tubes carry urine to the urinary bladder. To find these, you may need to wiggle the kidneys.
3. The urinary bladder is located between the umbilical vessels and stores urine.
4. Lift the bladder to locate the urethra, the tube that carries urine out of the body.
5. Note the vessels that attach to the kidney – these are the renal vessels.
Male
6. Find the scrotal sacs at the posterior end of the pig (between the legs), testes are located in each sac. Open the scrotal sac to locate the testes. ( Testes is plural, testis is singular.)
7. Coiled around the testis is the epididymis. Sperm cells produced in the testes pass through the epididymis and into a tube called the vas deferens (in humans, a vasectomy involves cutting this tube).
8. The penis can be located by cutting away the skin on the flap near the umbilical cord. This tube-like structure eventually exits out the urogenital opening, also known as the urethra.
9. Use the bold structures above to label the diagram:
10. Why does a vasectomy not affect urine flow? (Be specific with your answer using anatomical terms)
Female
11. In the female pig, locate a bean shaped ovary located near the kidneys and connect to the curly oviducts. The pig has a left and right ovary.
12. The curled oviducts are also referred to as uterine horns, which eventually merges at the uterus and then becomes the vagina. Piglets develop in the uterine horns, where a female can produce 12 or more piglets.
13. The urethra exits near the anus at the urogenital opening at the urogenital papilla.
14. Use the bold structures above to label the diagram:
15. What structures can be found in both the male and female urogenital systems?
16. In humans, eggs form in the ovary and then travel into the Fallopian tube where they are fertilized. The egg eventually implants into the uterus. What part of the pig anatomy is comparable to the Fallopian tube in humans?
17. Compare the location of the urogenital opening in female pigs to the urogenital opening in male pigs.
16. Consider a pig that has only one fully formed ovary. How would this affect the pig’s future reproduction?
Dissection of the Thoracic Cavity
You may need to cut through the pig's sternum and expose the chest cavity (thoracic cavity) to view. Identify each of the following organs.
1. Find the diaphragm again. Remember that the diaphragm separates the abdominal cavity from the thoracic cavity andit aids in breathing. Above the diaphragm is the heart and lungs.
2. Remove the pericardium, which is a thin membrane that surrounds the heart .
3. The structures visible on the heart are the two atria (12,13), ventricles (14).
4. The most obvious vessel on the front of the heart is the pulmonary trunk (1) . It curves upward and joins the aorta (2) - a vessel which arches fromthe heart and curves around to go to the lower part of the body -where it iscalled the abdominal (dorsal) aorta (9). The aorta supplies the body with blood.
5. The aorta has two branches above the heart- the right brachiocephalic (3) and the left subclavian (5)
6. The right brachiocephalic then branches into arteries - the common carotid (4) and the right subclavian (10) The subclavians supply blood to the arms andfollow the clavicle bone
7. The common carotid (4), branches into the left (7) and right carotidarteries (8). The carotid arteries supply blood to the head and neck.
8. Locate the coronary vessels (6) on the outside of the heart - these vesselssupply blood to the muscle of the heart.
9. Easy arteries to find are the ones that run near the ribs. These are theintercostal arteries (11).
10. Lift the heart to look on its dorsal side (toward the back), you should beable to see the anterior and posterior vena cava, which brings blood from thebody back to the heart.
11. Find the leftand right jugular veins. in the neck near the carotid arteries. These drain blood from the head.
12. Locate two spongy lungs located to the leftand right side of the heart.
13. The trachea is the airway to the lungs and is easy to identify due to the cartilage rings, whichkeeps it from collapsing. The trachea shouldbe located in the neck area.
13. Lying atop the trachea, locate the pinkish-brown, V shaped structure calledthe thyroid gland. This gland secretes hormones that control growth and metabolism.
14. At the anterior (toward head) of the trachea, you can find the larynx (or voice box). The larynx allows the pig to produce sounds -grunts and oinks.
Identify by number:
Aorta ____ Dorsal Aorta ____ Pulmonary Trunk ___
Common carotid ____ Left & Right Carotid ____
Coronary vessels ___ Left Subclavian_____
Right Subclavian _____ Right Brachiocephalic _____
Right Atrium _____ Left Atrium _____
Intercostal _____ Ventricle _____
Identify the structure.
1. _________________________________ Membrane over the heart.
2. _________________________________ Airway from mouth to lungs
3. _________________________________ Blood supply to head and neck
4. _________________________________ Lower heart chambers
5. _________________________________ Blood supply to lower body
6. _________________________________ Large veins that return blood to the heart
7. _________________________________ Vessel that leaves the heart and joins aorta
8. _________________________________ Used to make noises (voicebox)
9. ________________________________ Arteries on heart surface.
10. ________________________________ Supplies blood to the arms
11. ________________________________ Drains blood from the head and brain (returns to the heart)
12. ________________________________ Splits into the left and right carotid arteries
13. _________________________________ Muscle to aid breathing (separates abdominal and thoracic cavity)
14. _________________________________ Gland that secretes hormones
Fetal Pig - Dissection of the LowerArteries
1. Trace the abdominal aorta (alsocalled the dorsal aorta) to the lower part of the body, careful tweezing ofthe tissue will reveal several places where it branches, though some of thearteries may have been cut when you removed organs of the digestive system.
2. The renal arteries lead to the kidney.
3. The mesenteric artery leads to the mesentery and branches into many smallervessels. Look in the small intestine to find this artery.
4. Trace the abdominal aorta and note where it joins the umbilical arteries.
5. The abdominal aorta splits into two large vessels that lead to each leg -the external iliac arteries will turn into the femoral arteries as they enterthe leg
6. Follow the umbilical artery toward the pig, you'll find that it branchesand a small artery stretches toward the posterior of the pig - this is the ilio-lumbarartery.
7. The deep femoral branches from the femoral artery and goes toward the back of the leg.
This work is licensed under a Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License.
Photo Credits: Fetal Pig images modified from images shared from Biodidac | | Body Cavity Labeling by biologycorner.com
Pig Clipart (top) from clker.com
Salivary Glands Image Credit: Fetal Pig Dissection Manual, Alexandra Altamura
1. Do you have space with a sink? Pigs are a lot more involved than frogs and the preservatives will need to be drained and pigs rinsed. This is not a good dissection for classrooms that do not have sinks.
2. Have your students completed the frog dissection? The pig is more advanced, students should have a basic understanding of dissection protocols.
3. Pigs will need to be ordered from a biological supply company. If they are not injected, the circulartory system is very difficult to view. Generally, 1 pig for two students is a good match, but you could get away with 3-4 students per pig.
4. Safety: Goggles are required for all dissections. Latex gloves are optional, though generally preferred. Students should always wash hands even if they wore gloves. Many chemicals will seep through the latex. I have switched to nitrile gloves because it provides more of a barrier from harsh chemicals, but they are slightly more expensive.
5. Assessment. I take a grade on the completion of this lab guide. But as worksheets go, you do want the students to work out the answers together and ask for help when needed. Generally I use a quick and easy method to grade it. Each section is worth 5 pts. If its completed and looks mostly right, then they get the full 5 pts. Reduce pts if there are blanks or incorrect answers.
The biggest part of their grade comes from the LAB PRACTICAL. This is where pigs are set up at stations with numbered or colored tags in the structures. Students have 1 minute at each station to identify the structure and write it on their answer sheet. This is done in complete silence with no working together. Depending on the class, I may or may not allow them a word bank. Honors classes do not get a word bank usually unless I have an IEP or student that needs differentiation. The sheets below can be printed for the practical, they are numbered 1-50, though you don’t need to use all of the blanks. Just make sure your practical contains enough stations to keep students busy. If you have 30 students, you can have 25 stations with questions, and 5 “rest stations” interspersed.
Lab Practical Blanks | .doc file
Also print out the fetal pig lab guide – this just lists all of the structures they need to find with a checkbox. It makes for a good reference and study guide.
Fetal Pig Dissection: External Anatomy
External Anatomy
1. Determine the sex of your pig by looking for the urogenital opening. On females, this opening is located near the anus. On males, the opening is located near the umbilical cord. Check the bags and packaging, they are often labeled with the pig’s sex. Make sure you mix them up within the classroom.
If your pig is female, you should also note that urogenital papilla is present near the genital opening. Males do not have urogenital papilla.
Both males and females have rows of nipples, and the umbilical cord will be present in both.
What sex is your pig? _________
2. Make sure you are familiar with terms of reference: anterior, posterior, dorsal, ventral. In addition, you’ll need to know the following terms
Medial: toward the midline or middle of the body
Lateral: toward the outside of the body
Proximal: close to a point of reference
Distal: farther from a point of reference
*label the sides on the pig picture above. On the pig picture, they should just labe the anterior, posterior, dorsal, ventral.
3. Open the pig’s mouth and locate the hard and soft palate on the roof of the mouth. Can you feel your own hard and soft palates with your tongue?
Note the taste buds (also known as sensory papillae) on the side of the tongue. Locate the esophagus at the back of the mouth. Feel the edge of the mouth for teeth. Does the fetal pig have teeth? _yes
Are humans born with teeth? ___ no _
Locate the epiglottis, a cone-shaped structure at the back of the mouth, a flap of skin helps to close this opening when a pig swallows. The pharynx is the cavity in the back of the mouth – it is the junction for food (esophagus) and air (trachea). To find the epiglottis, you will need to make deep cuts at the edges of the mouth, I also place a lot of pressure on the jaw to break it and to get the mouth to fully open. Students will often be too gentle opening the mouth.
4. Gestation for the fetal pig is 112-115 days. The length of the fetal pig can give you a rough estimate of its age.
11mm – 21 days | 17 mm – 35 days | 2.8 cm – 49 days
4 cm – 56 days | 22 cm – 100 days | 30 cm — birth
5. Observe the toes of the pig. How many toes are on the feet? _________________
Do they have an odd or even number of toes? ______odd toed – artiodactyls_________________
6. Observe the eyes of the pig, carefully remove the eyelid so that you can view the eye underneath. Does it seem well developed? Do you think pigs are born with their eyes open or shut? _____________eyes developed, they usually open their eyes within first day__________________
7. Carefully lay the pig on one side in your dissecting pan and cut away the skin from the side of the face and upper neck to expose the masseter muscle that works the jaw, lymph nodes, and salivary glands. The salivary glands kind of look like chewing gum, and are often lost if you cut too deeply. Salivary glands are usually in the same spot, near the cheek and jaw. Lymph nodes can be in different spots and be difficult to locate.
**Make sure you know the locations of all the bold words on this handout**
The Anatomy of the Fetal Pig (internal)
pig diagramIdentify the structures on the diagram.
1. _____esophagus___
2. _____liver_______________
Fetal Pig Dissection Answer Key
3. _____gall bladder_________
4. ____bile duct___________
5. ____stomach____________
6. ____duodenum_____________
7. ____pancreas______________
8. ____small intestine_______
9. ____spleen_____________
10. ___cecum_____________
11. ___large intestine__________
12. ___rectum_____________
13. ___umbilical arteries__________
Fetal Pig Dissection Lab Worksheet
Identify the organ (or structure)
14. _____pyloric sphincter valve____ Opening (valve) between stomach and small intestine.
15. _____gall bladder_____________ Stores bile, lies underneath the liver.
16. ___________cecum___________ A branch of the large intestine, a dead end.
17. ___________diaphragm________ Separates the thoracic and abdominal cavity; aids breathing.
18. ________mesentery___________ Membrane that holds the coils of the small intestine.
19. ________duodenum___________ The straight part of the small intestine just after the stomach.
20. _______bile duct______________ Empties bile into the duodenum from the gall bladder.
21. _______rectum_______________ The last stretch of the large intestine before it exits at the anus.
22. _______pancreas_____________ Bumpy structure under the stomach; makes insulin
23. _______bladder_______________ Lies between the two umbilical vessels.
Urinary and Reproductive Systems
1. Locate the kidneys; the tubes leading from the kidneys that carry urine are the ureters. The ureters carry urine to the urinary bladder – located between the umbilical vessels. To find the ureters, expose the kidney and wiggle it, the ureter is attached and you’ll see it move.
2. Lift the bladder to locate the urethra, the tube that carries urine out of the body. checkbox
3. Note the vessels that attach to the kidney – these are the renal vessels checkbox
Male
1. Find the scrotal sacs at the posterior end of the pig (between the legs), testis are located in each sac. Open the scrotal sac to locate the testis. checkbox
2. On each teste, find the coiled epididymis. Sperm cells produces in the teste pass through the epididymis and into a tube called the vas deferens (in humans, a vasectomy involves cutting this tube).checkbox
3. The penis can be located by cutting away the skin on the flap near the umbilical cord. This tube-like structure eventually exits out the urogenital opening, also known as the urethra. checkbox The penis of the fetal pig is actually pretty difficult to find because it is internal (this can lead for much hilarity in the lab as students try to locate the structure. A simple technique I use to find it is to find the area just behind the urethral opening and roll this area (its also where the umbilical arteries are attached) between the thumb and forefinger. You should feel a solid tube like structure just under the skin – this is the penis.
Female
4. In the female pig, locate two bean shaped ovaries located just posterior to the kidneys and connected to the curly oviducts. checkbox
5. Trace the oviducts toward the posterior to find that they merge at the uterus. Trace the uterus to the vagina. The vagina will actually will appear as a continuation of the uterus. checkbox
LABEL THE DIAGRAMS
urinary system femalemale
Dissection of the Thoracic Cavity
Identify by number:
Aorta __2__ Dorsal Aorta _9__Pulmonary Trunk _1_
Common carotid _4__ Left & Right Carotid _7,8__
Coronary vessels _6__ Left Subclavian__5__
Right Subclavian __10__ Right Brachiocephalic _3___
Right Atrium __12__ Left Atrium _13__
Intercostal __11___ Ventricle __14_
Identify the structure.
1. _______pericardium________ Membrane over the heart.
2. _____trachea________ Airway from mouth to lungs
3. ____carotids_______ Blood supply to head
4. ____ventricles_________ Lower heart chambers
5. ____dorsal aorta_______ Blood supply to lower body
6. ____diaphragm_______ Muscle to aid breathing
7. ____vena cava_______ Returns blood to heart
8. ____aorta (or pulmonary)____ Large vessel at top of heart
9. ____larynx______ Used to make noises
10. ___coronary______ Arteries on heart surface.
Fetal Pig – Dissection of the Lower Arteries
I often do this part as an “optional section”. Some students will work very fast and will need something to do while others catch up. I have also offered extra credit to students who can expose these arteries to view (cleanly), which gives them extra incentive to work on it. The problem is, if you are spending time with groups that are farther behind, then you don’t have a lot of time to help students with the arteries. Giving them extra credit encourages them to try, but also requires them to work on their own.
Fetal Pig Lab Guide Answers Pdf
1. Trace the abominal aorta (also called the dorsal aorta) to the lower part of the body, careful tweezing of the tissue will reveal several places where it branches, though some of the arteries may have been cut when you removed organs of the digestive system. checkbox
2. The hepatic artery leads to the liver. (may not be visible) checkbox
3. The splenic artery leads to the spleen (may not be visible) checkbox
4. The renal arteries lead to the kidney. checkbox
5. The mesenteric artery leads to the mesentery and branches into many smaller vessels. Look in the small intestine to find this artery. checkbox
6. Trace the abominal aorta and note where it joins the umbilical arteries. You will need to cut the muscle in the leg to trace the next vessels. Use a pin to carefully tease away the surrounding muscle and tissue. checkbox
7. The abominal aorta splits into two large vessels that lead to each leg – the external iliac arteries will turn into the femoral arteries as they enter the leg checkbox
8. Follow the umbilical artery toward the pig, you’ll find that it branches and a small artery stretches toward the posterior of the pig – this is the ilio-lumbar artery. checkbox
9. Follow the external iliac into the leg (carefully tease away muscle),it will branch into two arteries: the femoral (toward the outside of the leg) and the deep femoral (toward the back of the leg) checkbox
lower arteries
flow chart
Publisher: Biologycorner.com;
Creative Commons LicenseThis work is licensed under a Creative Commons Attribution-NonCommercial 3.0 Unported License.
